Model	AT-780
Vacuum Pump Capacity *1	100/200/300 m3/h
Seal  Length | S	780mm×2
Distance Between Seal Bar | B	765mm
Alignment Of Seal Bar
Chamber Depth | D	280mm
Chamber Size	960×930mm
Distance From Floor To Platform | A	800mm
Power*2	5.5kW
Connection*3	380V/50Hz,3Phase
Need Compressed Air	√
Net Weight / Gross Weight *4	655/725kg
Machine Size | W x L x H  (mm)	1200×2400×1090
Shipping Dimensions (mm)	1270×2470×1270
Circle Time	2-3/min

  *1 pump could be alternative and the red capacity is recommended          *2  in condition of recommended vacuum pump capacity

  *3 could be customized      *4  in condition of recommended vacuum pump capacity
